SIEMENS 6ES7138-4CB10-0AB0

Product Type: Digital Output Module

Condition: Brand New & in Stock

Origin: Germany

Service One-stop

Shipping Detail: Fedex and UPS etc

Warranty: 12 months

─ ● ─ ● ─ ● ─ ─ ● ─ ● ─ ● ─ ─ ● ─ ● ─ ● ─ ─ ● ─ ● ─ ● ── ● ─ ● ─ ● ─ ─ ● ─ ● ─ ● ─ ─ ● ─ ● ─ ● ─ ─ ● ─ ●

☆ Want to know more details

1. Module Type: Digital Output Module (16 outputs)
2. Voltage Rating: 24V DC
3. Output Type: Transistor outputs (Type: sourcing or sinking)
4. Maximum Current per Output: 0.5 A
5. Maximum Total Current: 4 A (for all outputs combined)
6. I/O Channel Type: 16 digital outputs (can be individually configured)
7. Diagnostics Support: Yes, with LED indicators for each output
8. Power Consumption: Approx. 2.5 W
9. Bus Communication: Connected to the PLC bus via the backplane
10. Isolation Galvanic isolation between outputs and PLC system
11. Environmental Operating Temperature: 0°C to +60°C

☆ Introduction to the

SiemensSIMATIC ET 200S Series

SIMATIC ET 200S is a modular distributed I/O systemthat offers flexible connectivity to a variety of controllers and fieldbuses. Supporting industrial communication protocols such as PROFIBUS DP and PROFINET IO, the system can be installed directly in the control cabinet or at the field level, enabling flexible distributed signal acquisition and output control.

The modular structure, consisting ofa base unit, electronics module, and front connector, allows users to freely expand or replace functional modules based on site needs, significantly reducing maintenance costs and improving system reliability.

─ ● ─ ● ─ ● ─ ─ ● ─ ● ─ ● ─ ─ ● ─ ● ─ ● ─ ─ ● ─ ● ─ ● ── ● ─ ● ─ ● ─ ─ ● ─ ● ─ ● ─ ─ ● ─ ● ─ ●─ ─ ●  ─ ●
